SOMMER安裝尺寸：GPP5003

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5003N-00-A

2.5 [mm]

150 [N]

140 [N]

GPP5003N-20-A

2.5 [mm]

150 [N]

140 [N]

GPP5003N-21-A

2.5 [mm]

150 [N]

140 [N]

GPP5003N-24-A

2.5 [mm]

150 [N]

140 [N]

GPP5003N-AL-A

2.5 [mm]

150 [N]

140 [N]

GPP5003NC-00-A

2.5 [mm]

-

195 [N]

GPP5003NC-20-A

2.5 [mm]

-

195 [N]

GPP5003NC-21-A

2.5 [mm]

-

195 [N]

GPP5003NC-24-A

2.5 [mm]

-

195 [N]

GPP5003NC-AL-A

2.5 [mm]

-

195 [N]

GPP5003NO-00-A

2.5 [mm]

205 [N]

-

GPP5003NO-20-A

2.5 [mm]

205 [N]

-

GPP5003NO-21-A

2.5 [mm]

205 [N]

-

GPP5003NO-24-A

2.5 [mm]

205 [N]

-

GPP5003NO-AL-A

2.5 [mm]

205 [N]

-

SOMMER安裝尺寸：GPP5004

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5004N-00-A

4 [mm]

215 [N]

200 [N]

GPP5004N-20-A

4 [mm]

215 [N]

200 [N]

GPP5004N-21-A

4 [mm]

215 [N]

200 [N]

GPP5004N-24-A

4 [mm]

215 [N]

200 [N]

GPP5004N-AL-A

4 [mm]

215 [N]

200 [N]

GPP5004NC-00-A

4 [mm]

-

280 [N]

GPP5004NC-20-A

4 [mm]

-

280 [N]

GPP5004NC-21-A

4 [mm]

-

280 [N]

GPP5004NC-24-A

4 [mm]

-

280 [N]

GPP5004NC-AL-A

4 [mm]

-

280 [N]

GPP5004NO-00-A

4 [mm]

295 [N]

-

GPP5004NO-20-A

4 [mm]

295 [N]

-

GPP5004NO-21-A

4 [mm]

295 [N]

-

GPP5004NO-24-A

4 [mm]

295 [N]

-

GPP5004NO-AL-A

4 [mm]

295 [N]

-

GPP5004S-00-A

2 [mm]

470 [N]

440 [N]

GPP5004S-20-A

2 [mm]

470 [N]

440 [N]

GPP5004S-21-A

2 [mm]

470 [N]

440 [N]

GPP5004S-24-A

2 [mm]

470 [N]

440 [N]

GPP5004SC-00-A

2 [mm]

-

600 [N]

GPP5004SC-20-A

2 [mm]

-

600 [N]

GPP5004SC-21-A

2 [mm]

-

600 [N]

GPP5004SC-24-A

2 [mm]

-

600 [N]

GPP5004SO-00-A

2 [mm]

630 [N]

-

GPP5004SO-20-A

2 [mm]

630 [N]

-

GPP5004SO-21-A

2 [mm]

630 [N]

-

GPP5004SO-24-A

2 [mm]

630 [N]

-

SOMMER安裝尺寸：GPP5006

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5006N-00-A

6 [mm]

360 [N]

330 [N]

GPP5006N-20-A

6 [mm]

360 [N]

330 [N]

GPP5006N-21-A

6 [mm]

360 [N]

330 [N]

GPP5006N-24-A

6 [mm]

360 [N]

330 [N]

GPP5006N-AL-A

6 [mm]

360 [N]

330 [N]

GPP5006NC-00-A

6 [mm]

-

455 [N]

GPP5006NC-20-A

6 [mm]

-

455 [N]

GPP5006NC-21-A

6 [mm]

-

455 [N]

GPP5006NC-24-A

6 [mm]

-

455 [N]

GPP5006NC-AL-A

6 [mm]

-

455 [N]

GPP5006NO-00-A

6 [mm]

485 [N]

-

GPP5006NO-20-A

6 [mm]

485 [N]

-

GPP5006NO-21-A

6 [mm]

485 [N]

-

GPP5006NO-24-A

6 [mm]

485 [N]

-

GPP5006NO-AL-A

6 [mm]

485 [N]

-

GPP5006S-00-A

3 [mm]

800 [N]

740 [N]

GPP5006S-20-A

3 [mm]

800 [N]

740 [N]

GPP5006S-21-A

3 [mm]

800 [N]

740 [N]

GPP5006S-24-A

3 [mm]

800 [N]

740 [N]

GPP5006SC-00-A

3 [mm]

-

1020 [N]

GPP5006SC-20-A

3 [mm]

-

1020 [N]

GPP5006SC-21-A

3 [mm]

-

1020 [N]

GPP5006SC-24-A

3 [mm]

-

1020 [N]

GPP5006SO-00-A

3 [mm]

1080 [N]

-

GPP5006SO-20-A

3 [mm]

1080 [N]

-

GPP5006SO-21-A

3 [mm]

1080 [N]

-

GPP5006SO-24-A

3 [mm]

1080 [N]

-

SOMMER安裝尺寸：GPP5008

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5008N-00-A

8 [mm]

560 [N]

520 [N]

GPP5008N-20-A

8 [mm]

560 [N]

520 [N]

GPP5008N-21-A

8 [mm]

560 [N]

520 [N]

GPP5008N-24-A

8 [mm]

560 [N]

520 [N]

GPP5008N-AL-A

8 [mm]

560 [N]

520 [N]

GPP5008NC-00-A

8 [mm]

-

710 [N]

GPP5008NC-20-A

8 [mm]

-

710 [N]

GPP5008NC-21-A

8 [mm]

-

710 [N]

GPP5008NC-24-A

8 [mm]

-

710 [N]

GPP5008NC-AL-A

8 [mm]

-

710 [N]

GPP5008NO-00-A

8 [mm]

750 [N]

-

GPP5008NO-20-A

8 [mm]

750 [N]

-

GPP5008NO-21-A

8 [mm]

750 [N]

-

GPP5008NO-24-A

8 [mm]

750 [N]

-

GPP5008NO-AL-A

8 [mm]

750 [N]

-

GPP5008S-00-A

4 [mm]

1240 [N]

1150 [N]

GPP5008S-20-A

4 [mm]

1240 [N]

1150 [N]

GPP5008S-21-A

4 [mm]

1240 [N]

1150 [N]

GPP5008S-24-A

4 [mm]

1240 [N]

1150 [N]

GPP5008SC-00-A

4 [mm]

-

1580 [N]

GPP5008SC-20-A

4 [mm]

-

1580 [N]

GPP5008SC-21-A

4 [mm]

-

1580 [N]

GPP5008SC-24-A

4 [mm]

-

1580 [N]

GPP5008SO-00-A

4 [mm]

1670 [N]

-

GPP5008SO-20-A

4 [mm]

1670 [N]

-

GPP5008SO-21-A

4 [mm]

1670 [N]

-

GPP5008SO-24-A

4 [mm]

1670 [N]

-

SOMMER安裝尺寸：GPP5010

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5010N-00-A

10 [mm]

945 [N]

885 [N]

GPP5010N-20-A

10 [mm]

945 [N]

885 [N]

GPP5010N-21-A

10 [mm]

945 [N]

885 [N]

GPP5010N-24-A

10 [mm]

945 [N]

885 [N]

GPP5010N-AL-A

10 [mm]

945 [N]

885 [N]

GPP5010NC-00-A

10 [mm]

-

1260 [N]

GPP5010NC-20-A

10 [mm]

-

1260 [N]

GPP5010NC-21-A

10 [mm]

-

1260 [N]

GPP5010NC-24-A

10 [mm]

-

1260 [N]

GPP5010NC-AL-A

10 [mm]

-

1260 [N]

GPP5010NO-00-A

10 [mm]

1320 [N]

-

GPP5010NO-20-A

10 [mm]

1320 [N]

-

GPP5010NO-21-A

10 [mm]

1320 [N]

-

GPP5010NO-24-A

10 [mm]

1320 [N]

-

GPP5010NO-AL-A

10 [mm]

1320 [N]

-

GPP5010S-00-A

5 [mm]

2080 [N]

1940 [N]

GPP5010S-20-A

5 [mm]

2080 [N]

1940 [N]

GPP5010S-21-A

5 [mm]

2080 [N]

1940 [N]

GPP5010S-24-A

5 [mm]

2080 [N]

1940 [N]

GPP5010SC-00-A

5 [mm]

-

2750 [N]

GPP5010SC-20-A

5 [mm]

-

2750 [N]

GPP5010SC-21-A

5 [mm]

-

2750 [N]

GPP5010SC-24-A

5 [mm]

-

2750 [N]

GPP5010SO-00-A

5 [mm]

2890 [N]

-

GPP5010SO-20-A

5 [mm]

2890 [N]

-

GPP5010SO-21-A

5 [mm]

2890 [N]

-

GPP5010SO-24-A

5 [mm]

2890 [N]

-

SOMMER安裝尺寸：GPP5013

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5013N-00-A

13 [mm]

1490 [N]

1410 [N]

GPP5013N-20-A

13 [mm]

1490 [N]

1410 [N]

GPP5013N-21-A

13 [mm]

1490 [N]

1410 [N]

GPP5013N-24-A

13 [mm]

1490 [N]

1410 [N]

GPP5013NC-00-A

13 [mm]

-

1920 [N]

GPP5013NC-20-A

13 [mm]

-

1920 [N]

GPP5013NC-21-A

13 [mm]

-

1920 [N]

GPP5013NC-24-A

13 [mm]

-

1920 [N]

GPP5013NO-00-A

13 [mm]

1860 [N]

-

GPP5013NO-20-A

13 [mm]

1860 [N]

-

GPP5013NO-21-A

13 [mm]

1860 [N]

-

GPP5013NO-24-A

13 [mm]

1860 [N]

-

GPP5013S-00-A

6 [mm]

3280 [N]

3100 [N]

GPP5013S-20-A

6 [mm]

3280 [N]

3100 [N]

GPP5013S-21-A

6 [mm]

3280 [N]

3100 [N]

GPP5013S-24-A

6 [mm]

3280 [N]

3100 [N]

GPP5013SC-00-A

6 [mm]

-

4220 [N]

GPP5013SC-20-A

6 [mm]

-

4220 [N]

GPP5013SC-21-A

6 [mm]

-

4220 [N]

GPP5013SC-24-A

6 [mm]

-

4220 [N]

GPP5013SO-00-A

6 [mm]

4400 [N]

-

GPP5013SO-20-A

6 [mm]

4400 [N]

-

GPP5013SO-21-A

6 [mm]

4400 [N]

-

GPP5013SO-24-A

6 [mm]

4400 [N]

-

SOMMER安裝尺寸：GPP5016

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5016N-00-A

16 [mm]

2220 [N]

2090 [N]

GPP5016N-20-A

16 [mm]

2200 [N]

2090 [N]

GPP5016N-21-A

16 [mm]

2220 [N]

2090 [N]

GPP5016N-24-A

16 [mm]

2220 [N]

2090 [N]

GPP5016NC-00-A

16 [mm]

-

2860 [N]

GPP5016NC-20-A

16 [mm]

-

2860 [N]

GPP5016NC-21-A

16 [mm]

-

2860 [N]

GPP5016NC-24-A

16 [mm]

-

2860 [N]

GPP5016NO-00-A

16 [mm]

2990 [N]

-

GPP5016NO-20-A

16 [mm]

2990 [N]

-

GPP5016NO-21-A

16 [mm]

2990 [N]

-

GPP5016NO-24-A

16 [mm]

2990 [N]

-

GPP5016S-00-A

8 [mm]

4900 [N]

4610 [N]

GPP5016S-20-A

8 [mm]

4900 [N]

4610 [N]

GPP5016S-21-A

8 [mm]

4900 [N]

4610 [N]

GPP5016S-24-A

8 [mm]

4900 [N]

4610 [N]

GPP5016SC-00-A

8 [mm]

-

6310 [N]

GPP5016SC-20-A

8 [mm]

-

6310 [N]

GPP5016SC-21-A

8 [mm]

-

6310 [N]

GPP5016SC-24-A

8 [mm]

-

6310 [N]

GPP5016SO-00-A

8 [mm]

6600 [N]

-

GPP5016SO-20-A

8 [mm]

6600 [N]

-

GPP5016SO-21-A

8 [mm]

6600 [N]

-

GPP5016SO-24-A

8 [mm]

6600 [N]

-

SOMMER安裝尺寸：GPP5025

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5025N-00-A

25 [mm]

3490 [N]

3280 [N]

GPP5025N-20-A

25 [mm]

3490 [N]

3280 [N]

GPP5025N-21-A

25 [mm]

3490 [N]

3280 [N]

GPP5025N-24-A

25 [mm]

3490 [N]

3280 [N]

GPP5025NC-00-A

25 [mm]

-

4510 [N]

GPP5025NC-20-A

25 [mm]

-

4510 [N]

GPP5025NC-21-A

25 [mm]

-

4510 [N]

GPP5025NC-24-A

25 [mm]

-

4510 [N]

GPP5025NO-00-A

25 [mm]

4710 [N]

-

GPP5025NO-20-A

25 [mm]

4710 [N]

-

GPP5025NO-21-A

25 [mm]

4710 [N]

-

GPP5025NO-24-A

25 [mm]

4710 [N]

-

GPP5025S-00-A

14 [mm]

6760 [N]

6360 [N]

GPP5025S-20-A

14 [mm]

6760 [N]

6360 [N]

GPP5025S-21-A

14 [mm]

6760 [N]

6360 [N]

GPP5025S-24-A

14 [mm]

6760 [N]

6360 [N]

GPP5025SC-00-A

14 [mm]

-

8730 [N]

GPP5025SC-20-A

14 [mm]

-

8730 [N]

GPP5025SC-21-A

14 [mm]

-

8730 [N]

GPP5025SC-24-A

14 [mm]

-

8730 [N]

GPP5025SO-00-A

14 [mm]

9130 [N]

-

GPP5025SO-20-A

14 [mm]

9130 [N]

-

GPP5025SO-21-A

14 [mm]

9130 [N]

-

GPP5025SO-24-A

14 [mm]

9130 [N]

-

SOMMER安裝尺寸：GPP5030

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5030N-00-A

30 [mm]

5210 [N]

5000 [N]

GPP5030N-20-A

30 [mm]

5210 [N]

5000 [N]

GPP5030N-21-A

30 [mm]

5210 [N]

5000 [N]

GPP5030N-24-A

30 [mm]

5210 [N]

5000 [N]

GPP5030NC-00-A

30 [mm]

-

6850 [N]

GPP5030NC-20-A

30 [mm]

-

6850 [N]

GPP5030NC-21-A

30 [mm]

-

6850 [N]

GPP5030NC-24-A

30 [mm]

-

6850 [N]

GPP5030NO-00-A

30 [mm]

7060 [N]

-

GPP5030NO-20-A

30 [mm]

7060 [N]

-

GPP5030NO-21-A

30 [mm]

7060 [N]

-

GPP5030NO-24-A

30 [mm]

7060 [N]

-

GPP5030S-00-A

17 [mm]

9990 [N]

9600 [N]

GPP5030S-20-A

17 [mm]

9990 [N]

9600 [N]

GPP5030S-21-A

17 [mm]

9990 [N]

9600 [N]

GPP5030S-24-A

17 [mm]

9990 [N]

9600 [N]

GPP5030SC-00-A

17 [mm]

-

13160 [N]

GPP5030SC-20-A

17 [mm]

-

13160 [N]

GPP5030SC-21-A

17 [mm]

-

13160 [N]

GPP5030SC-24-A

17 [mm]

-

13160 [N]

GPP5030SO-00-A

17 [mm]

13550 [N]

-

GPP5030SO-20-A

17 [mm]

13550 [N]

-

GPP5030SO-21-A

17 [mm]

13550 [N]

-

GPP5030SO-24-A

17 [mm]

13550 [N]

-

SOMMER安裝尺寸：GPP5035

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5035N-00-A

35 [mm]

6300 [N]

6100 [N]

GPP5035N-20-A

35 [mm]

6300 [N]

6100 [N]

GPP5035N-21-A

35 [mm]

6300 [N]

6100 [N]

GPP5035N-24-A

35 [mm]

6300 [N]

6100 [N]

GPP5035NC-00-A

35 [mm]

-

8000 [N]

GPP5035NC-20-A

35 [mm]

-

8000 [N]

GPP5035NC-21-A

35 [mm]

-

8000 [N]

GPP5035NC-24-A

35 [mm]

-

8000 [N]

GPP5035NO-00-A

35 [mm]

8200 [N]

-

GPP5035NO-20-A

35 [mm]

8200 [N]

-

GPP5035NO-21-A

35 [mm]

8200 [N]

-

GPP5035NO-24-A

35 [mm]

8200 [N]

-

GPP5035S-00-A

20 [mm]

12100 [N]

11700 [N]

GPP5035S-20-A

20 [mm]

12100 [N]

11700 [N]

GPP5035S-21-A

20 [mm]

12100 [N]

11700 [N]

GPP5035S-24-A

20 [mm]

12100 [N]

11700 [N]

GPP5035SC-00-A

20 [mm]

-

15500 [N]

GPP5035SC-20-A

20 [mm]

-

15500 [N]

GPP5035SC-21-A

20 [mm]

-

15500 [N]

GPP5035SC-24-A

20 [mm]

-

15500 [N]

GPP5035SO-00-A

20 [mm]

15900 [N]

-

GPP5035SO-20-A

20 [mm]

15900 [N]

-

GPP5035SO-21-A

20 [mm]

15900 [N]

-

GPP5035SO-24-A

20 [mm]

15900 [N]

-

SOMMER安裝尺寸：GPP5045

訂貨號

單邊行程

張開抓取力

閉合抓取力

GPP5045N-00-A

45 [mm]

10700 [N]

10200 [N]

GPP5045N-20-A

45 [mm]

10700 [N]

10200 [N]

GPP5045N-21-A

45 [mm]

10700 [N]

10200 [N]

GPP5045N-24-A

45 [mm]

10700 [N]

10200 [N]

GPP5045NC-00-A

45 [mm]

-

13700 [N]

GPP5045NC-20-A

45 [mm]

-

13700 [N]

GPP5045NC-21-A

45 [mm]

-

13700 [N]

GPP5045NC-24-A

45 [mm]

-

13700 [N]

GPP5045NO-00-A

45 [mm]

14200 [N]

-

GPP5045NO-20-A

45 [mm]

14200 [N]

-

GPP5045NO-21-A

45 [mm]

14200 [N]

-

GPP5045NO-24-A

45 [mm]

14200 [N]

-

GPP5045S-00-A

26 [mm]

20300 [N]

19400 [N]

GPP5045S-20-A

26 [mm]

20300 [N]

19400 [N]

GPP5045S-21-A

26 [mm]

20300 [N]

19400 [N]

GPP5045S-24-A

26 [mm]

20300 [N]

19400 [N]

GPP5045SC-00-A

26 [mm]

-

26050 [N]

GPP5045SC-20-A

26 [mm]

-

26050 [N]

GPP5045SC-21-A

26 [mm]

-

26050 [N]

GPP5045SC-24-A

26 [mm]

-

26050 [N]

GPP5045SO-00-A

26 [mm]

26950 [N]

-

GPP5045SO-20-A

26 [mm]

26950 [N]

-

GPP5045SO-21-A

26 [mm]

26950 [N]

-

GPP5045SO-24-A

26 [mm]

26950 [N]

-

楔形塊機構

支撐承受高作用力和力矩

抓手手指同步運動

抓手手指

運用可拆卸的定心套筒安裝手指

通過內置潤滑槽實現持久潤滑

鋼制線性導軌

鋼以鋼軌為導向

可安裝超長手指

也有鋼/ 鋁版本

安裝塊

安裝接近開關

內置保持力安全裝置

氣缸室內置彈簧作為蓄能器

驅動

雙作用氣缸

安裝和定位

可選擇在多個側面個性化安裝

氣動和電動版本除了高度尺寸外均相同

檢測槽

用于安裝磁性傳感器

雙唇密封件

IP64，防護等級IP67（帶空氣增壓密封）

防止油脂溢出，提高使用壽命
